Greatly improve the concrete smoothness and compaction.
Prolong the service life of concrete floor
Used in modern industrial workshop, large shopping malls warehouse
Greatly improve the concrete smoothness and compaction.
Prolong the service life of concrete floor
Used in modern industrial workshop, large shopping malls warehouse
| Model | FLS-400 | |
| Dimension mm | L3155*W3175*H1910 | |
| Weight kg | 741 | |
| Engine Model | Kohler CH620 | |
| Engine type | Petrol, V-cylinder engine, air cooling | |
| Engine Power kw | 14.2 | |
| Lubricating oil L | 2 | |
| Fuel tank Capacity L | 35 | |
| Type of Leveling | Independent suspension、Center rotation | |
| Paving Width mm | 2500 | |
| Paving Way | scraper blade paving | |
| Paving thickness mm | 30–200 | |
| Boom Motor | High torque hydraulic motor | |
| Vibrating System control | Vibrating motor | |
| Exciting force kg | 100 | |
| Vibrational Frequency hz | 50 | |
| Laser System Control Type | Laser Scanning+High sensitivity DC push rod | |
| Laser System Control effect | Flat surface, Slope floor | |
| Driving System | Hydraulic driving tyre | |
| Wheel | Heavy-duty tyre | |
| Walking Speed km/h | 0-2.5 | |
| Seat | NO Seat | |
| Forward/backward | Switch Control, Stepless speed | |
| Turing | Switch control | |
